Kelly Kan Seals
A quick exchange of seals and top plates enables the Kelly Kan™ to fit the Kelly, drill pipe, test tools, and other parts on the string from 2 3/8” to 7.5”
Product Documents
A quick exchange of seals and top plates enables the Kelly Kan™ to fit the Kelly, drill pipe, test tools, and other parts on the string from 2 3/8” to 7.5”
Features
Regular seals (grey) remain flexible in temperatures between -40°C to 100°C and high temp seals (black) remain flexible in temperatures between -75°C to 190° C
Kelly Kan™ seals work in conjunction with the Top Plates
Drill Pipe SizeTool Joint SizeCompatible Seal SizeSeal Part #Top Plate SizeTop Plate Part #
| 2-3/8” (60.32mm) | 2-1/2” (63.5mm) | 2-3/8” (60.32mm) | KK001-1 | 2-7/8" (73.02mm) | KK005-2 |
| 2-7/8” (73.03mm) | 2-7/8” (73.03mm) | KK001-1.5 | |||
| 3" to 3-1/4" (76.20 to 82.55mm) | 3” (76.20mm) | KK001-2 | |||
| 3-3/8" to 3-3/4" (85.73 to 94.25mm) | 3-1/2” (88.90mm) | KK001-2.5 | |||
| 2-7/8” (73.02mm) | 3” to 3-1/4” (76.20 to 82.55mm) | 3" (76.20mm) | KK001-2 | 3-1/2" (88.90mm) | KK005-3 |
| 3-3/8” to 3-3/4” (85.73 to 95.25mm) | 3-1/2" (88.90mm) | KK001-2.5 | |||
| 3-7/8" to 4-1/4" (98.43 to 107.95mm) | 4" (101.60mm) | KK001-3 | |||
| 4-3/8" to 4-3/4" (111.13 to 120.65mm) | 4-1/2" (114.30mm) | KK001-3.5 | |||
| 3-1/2” (88.90mm) | 3-7/8" to 4-1/4" (98.43 to 107.95mm) | 4" (101.60mm) | KK001-3 | 3-3/4" (94.25mm) | KK005-4 |
| 4-3/8” to 4-3/4” (111.13 to 120.65mm) | 4-1/2" (114.30mm) | KK001-3.5 | |||
| 4-7/8” to 5-1/4” (123.83 to 133.35mm) | 5" (127.00mm) | KK001-4 | |||
| 5-3/8” to 5-3/4" (136.53 to 146.05mm) | 5-1/2" (139.70mm) | KK001-4.5 | |||
| 4” (101.60mm) | 4-3/8" to 4-3/4" (111.13 to 120.65mm) | 4-1/2" (114.30mm) | KK001-3.5 | 4-1/2" (114.30mm) | KK005-4.5 |
| 4-7/8" to 5-1/4" (123.83 to 133.35mm) | 5" (127.00mm) | KK001-4 | |||
| 5-3/8" to 5-3/4" (136.53 to 146.05mm) | 5-1/2" (139.70mm) | KK001-4.5 | |||
| 5-7/8" to 6-1/4" (149.23 to 158.75mm) | 6" (152.40mm) | KK001-5 | |||
| 4-1/2” (114.30mm) | 4-7/8" to 5-1/4" (123.83 to 133.35mm) | 5" (127.00mm) | KK001-4 | 4-3/4" (120.65mm) | KK005-5 |
| 5-3/8" to 5-3/4" (136.53 to 146.05mm) | 5-1/2" (139.60mm) | KK001-4.5 | |||
| 5-7/8" to 6-1/4" (149.23 to 158.75mm) | 6" (152.40mm) | KK001-5 | |||
| 6-3/8" to 6-3/4" (161.92 to 171.45mm) | 6-1/2" (165.10mm) | KK001-6 | |||
| 5” (127.00mm) | 6-3/8" to 6-3/4" (161.92 to 171.45mm) | 6-1/2" (165.10mm) | KK001-6 | 5-3/4" (146.05mm) | KK005-6 |
| 6-7/8" to 7-1/4" (174.63 to 184.15mm) | 7" (177.80mm) | KK001-7 | |||
| 5-1/2" (139.70mm) | 6-3/8” to 6-3/4” (161.92 to 171.45mm) | 6-1/2" (165.10mm) | KK001-6 | 5-3/4" (146.05mm) | KK005-6 |
| 6-7/8" to 7-1/4" (174.63 to 184.15mm) | 7" (177.80mm) | KK001-7 | |||
| 7-3/8" to 7-3/4" (187.33 to 196.85mm) | 7-1/2" (190.50mm) | KK001-7.5 | |||
| 5-7/8” (149.23mm) | 6-7/8" to 7-1/4" (174.63 to 184.15mm) | 7" (177.80mm) | KK001-7 | 6-1/2" (165.10mm) | KK005-7 |
| 6-5/8" (168.28mm) | 7-7/8" to 8" (200.03 to 203.20mm) | 8" (203.20mm) | KK001-8 | None | None |
Additional information
| Kelly Kan™ Seal for Tool Joint Part # | KK001-1, KK001-1.5, KK001-2, KK001-2.5, KK001-3, KK001-3.5, KK001-4, KK001-4.5, KK001-5, KK001-6, KK001-7, KK001-7.5, KK001-8 |
|---|
